Halogen-free flame retardant thermal fluid (beam)
Halogen-free flame retardant thermal fluid (beam) covering materials for cable insulation
Product code:05002
This is a used halogen-free flame retardant heat curing (beam) of wire and cable insulation materials, it does not emit toxic gases and, has excellent performance, low smoke zero halogen and is suitable for wire and cable insulation and solar cells.
Application
－IEC 60092－359 SHF 2
－UL 3271 UL 3266,CSA AWM 1A/B
－EN 50265－２－1, EN 50266－２－４, EN 50267－２
－BS EN 50264－１
－Railway, industrial, and marine areas
Performance
|
Item |
Unit |
Test method |
05002 |
||
|
Density @23℃ |
g/cc |
ASTM D792 |
1.30 |
||
|
Tensile strength |
MPa |
IEC 60811-1-1 |
15 |
||
|
Elongation at break |
% |
420 |
|||
|
After ageing(150℃/168hrs) |
T.S retention |
% |
IEC 60811-1-2 |
90 |
|
|
Elongation retention |
% |
85 |
|||
|
Thermalization, install (200℃/15m,in ,20N/15com)
|
load elongation
|
% |
IEC 60811-2-1 |
45 |
|
|
Permanent elongation |
% |
2.5 |
|||
|
Oil resistance (ASTM #2 Oil 100℃,72hrs) |
Tensile strength |
Kgf/cm |
IEC 60811-1-2 |
80 |
|
|
Elongation at break |
% |
80 |
|||
|
Hot pressure test(90℃) |
% |
IEC 60811-3-1 |
0 |
||
|
Cold impact test (-15℃) |
- |
IEC 60811-1-4 |
pass |
||
|
Smoke density |
Flaming |
Ds Max |
ASTM E662 |
- |
|
|
No Flaming (0.5mm) |
80 |
||||
|
Corrosion test |
pH |
- |
IEC 60754-2 |
5 |
|
|
conductivity |
µs/㎜ |
3.8 |
|||
|
Halogen acid gas evolution |
% |
IEC 60754-1 |
0.1 |
||
|
Oxygen index |
% |
ASTM D2863 |
34 |
||
|
Volume resistivity |
Ω.m |
ASTM D257 |
1*1015 |
||
|
Hardness |
Shore A |
ASTM D2240 |
95 |
||
|
curing condition |
|
|
1Mev*20Mrad |
||
Processing
|
C1 |
C2 |
C3 |
C4 |
C5 |
Neck |
Head |
Die |
|
150 |
160 |
170 |
175 |
180 |
180 |
180 |
185 |
Recommend to use conventional extruder (with a three-stage or PE/PVC protective screen type cuts screw, length to diameter ratio of 24:1, and compression ratio of 3:1) for extrusion operation.
Storage
- Keep from10 to 30 degrees centigrade at room temperature
- Six- month shelf life in clean and dry environment
- If opened for a long time, please use dryer to dry it in 65-70 degrees centigrade for 3-4 hours.
- In order to ensure safety, please refer to the material safety data sheet
Packing
Each case content is ５００ｋｇ（Aluminum foil paper carton）
Each package content is 25kg.（Aluminum foil bag）
User Service
we will provide the user service according to the different needs of customers.
